IEC 61300-3-53 Ed. 1.0 en:2015 Fibre optic interconnecting devices and passive components - Basic test and measurement procedures - Part 3-53: Examinations and measurements - Encircled angular flux (EAF) measurement method based on two-dimensional far field data from step index multimode waveguide (including fibre)

standard by International Electrotechnical Commission, 02/05/2015

More details

In stock

$51.48

-56%

$117.00

More info

Full Description

IEC 61300-3-53:2015(E) is intended to characterize the encircled angular flux of measurement step index multimode waveguide light sources, in which most of the transverse modes are excited. The term waveguide is understood to include both channel waveguides and optical fibres but not slab waveguides in this standard. Encircled angular flux (EAF) is the fraction of the total optical power radiating from a step index multimode waveguide's core within a certain solid angle. The EAF is measured as a function of the numerical aperture full angle. The basic approach is to collect, for every measurement, two dimensional far field data using a calibrated camera and to convert them mathematically into encircled angular flux. Keywords: encircled angular flux (EAF), measurement step index multimode waveguide light sources

Product Details

Edition: 1.0 Published: 02/05/2015 Number of Pages: 20 File Size: 1 file , 560 KB
