> >IEC 61169-51 Ed. 1.0 b:2015
Reduced price! IEC 61169-51 Ed. 1.0 b:2015 View larger

IEC 61169-51 Ed. 1.0 b:2015

M00000846

New product

IEC 61169-51 Ed. 1.0 b:2015 Radio-frequency connectors - Part 51: Sectional specification for RF coaxial connectors with inner diameter of outer conductors 13,5 mm with bayonet lock - Characteristic impedance 50 ¿¿ (type QLI)

standard by International Electrotechnical Commission, 02/05/2015

More details

In stock

$87.56

-56%

$199.00

More info

Full Description

IEC 61169-51:2015 provides information and rules for the preparation of detail specifications (DS) for type QLI R.F. coaxial connectors with quick lock. The connectors are normally used with 50 Ohms corrugated cable and flexible cables for middle power applications in an operating range up to 6 GHz. It describes the interface dimensions for general purpose connectors with gauging information and the mandatory tests selected from IEC 61169-1 applicable to all detail specifications relative to type QLI connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers all tests schedules and inspection requirements.

Product Details

Edition: 1.0 Published: 02/05/2015 Number of Pages: 53 File Size: 1 file , 1.2 MB
