> >IEC 61169-50 Ed. 1.0 b:2014
Reduced price! IEC 61169-50 Ed. 1.0 b:2014 View larger

IEC 61169-50 Ed. 1.0 b:2014

M00001391

New product

IEC 61169-50 Ed. 1.0 b:2014 Radio-frequency connectors - Part 50: Sectional specification for RF coaxial connectors with inner diameter of outer conductors 4,11 mm with quick lock system - Characteristics impedance 50 Ohm (type QMA)

standard by International Electrotechnical Commission, 10/23/2014

More details

In stock

$72.16

-56%

$164.00

More info

Full Description

IEC 61169-50:2014, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for type QMA R.F. coaxial connectors with quick lock. The connectors are normally used with 50 Ohms corrugated cable and flexible cables for middle power applications in an operating range up to 6 GHz. It describes the interface dimensions for general purpose connectors with gauging information and the mandatory tests selected from IEC 61169-1, applicable to all detail specifications relative to type QMA connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers all tests schedules and inspection requirements.

Product Details

Edition: 1.0 Published: 10/23/2014 Number of Pages: 42 File Size: 1 file , 620 KB
