IEC 61188-5-5 Ed. 1.0 b:2007
M00001682
New product
IEC 61188-5-5 Ed. 1.0 b:2007 Printed boards and printed board assemblies - Design and use - Part 5-5: Attachment (land/joint) considerations - Components with gull-wing leads on four sides
standard by International Electrotechnical Commission, 10/30/2007
In stock
More info
Full Description
IEC 61188-5-5:2007 provides information on land pattern geometries used for the surface attachment of electronic components with gull-wing leads on four sides. The intent of the information presented herein is to provide the appropriate size, shape and tolerances of surface mount land patterns to ensure sufficient area for the appropriate solder fillet, and also allow for inspection, testing and reworking of those solder joints.This publication is to be read in conjunction with IEC 61188-5-1 :2002.
